Total Nitrogen/Sulfur/Chlorine Analyzer - TN/TS/TX 6000

The TSHR Total Nitrogen/Sulfur/Chlorine Analyzer, model TN/TS/TX 6000, is the ideal solution for limited sample throughput labs but with multi-element analysis requirements in a single combustion elemental analyser. The analyzer supports a wide range of petrochemical and refinery applications such as liquids, solids and LPG/Gas sample types.

The TN/TS/TX 6000 combines enhanced performance with excellent uptime, matrix independence and exceptional linearity.

The TN/TS/TX 6000 model makes use of horizontal sample introduction and high temperature oxidation followed by UV-Fluorescence (TS-UVF) and chemiluminescence (TN-CLD) detection, which makes it possible to perform a simultaneous Total Nitrogen and Total Sulfur analysis. For TX (Total Chlorine) analysis, the analyzer is equipped with a TX module which includes the cooled microcoulometric titration cell.

Key Features

  • Simultaneous Total Sulfur + Nitrogen data down to 50 ppb
  • Application flexibility with syringe and boat sample introduction modules
  • TX module for accurate and fast Total Chlorine analysis
  • Enhanced application range for solids, liquids and LPG/Gasses

International Regulatory Compliance Methods

Documents
